700C Carbon Fiber Track Bike Time Trail Frame

700C Carbon Fiber Track Bike Time Trail Frame

700C Carbon Fiber Track Bike Time Trail Frame is constructed from Toray T700&T800.This uses BB30 or BSA system and weighs about 1300g.

  • Item NO.:

    FM-R845
  • Order(MOQ):

    10
  • Payment:

    Paypal, Bank Transfer, West Union
  • Product Origin:

    Xiamen,China
  • Color:

    UD Matte/Glossy/painting
  • Product Detail

Carbon Fiber Track Bike Time Trail Frame



Product Feature

  • Super lightweight, frame constructed with premium Toray T700 & T800 carbon fiber, best strength to weight ratio with no expense spared.
  • Available in press fit BSA or BB30 bottom bracket system, of great stiffness.
  • This carbon TT bike frame includes frame(about 1300g) and fork(about 390g).


Specification

Item NO.
FM-R845
Type:
700C carbon time trial bike frame
Material:
100% Carbon Fiber Toray T700 & T800
Weave:
 Matte/Glossy/painting
Finish: UD/3K/12K
Available size:
461,481,502,522,543
Headset:
1-1/8''(top)/1-1/2''(down)
Bottom Bracket
BSA or BB30
Weight:
from 1300g fork:390g


Product Geometry


Carbon Fiber Track Bike Time Trail Frame


SIZE A B C D E F G H I J K
461 68 385 581.4 956.4 461 557.2 83.5 365 43 71.6 80
481 68 385 601.2 984 481 575.5 103.9 365 43 71.8 80
502 68 385 620.8 996 502 594.2 124.2 365 43 72 80
522 68 385 639.4 1014.7 522 613.1 144.2 365 43 72.2 80
543 68 385 659.7 1035.1 543 632.6 164.8 365 43 72.4 80


Read More For Production Of Carbon Frames By Top-Fire Factory


Read More For Testing Of Carbon Frames By Top-Fire Factory
