Top-Fire 700C 20mm Width 20mm Depth Lightweight Hub Tubular Rim Brake Carbon Wheelset For Road Bike

Top-Fire 700C 20mm Width 20mm Depth Lightweight Hub Tubular Rim Brake Carbon Wheelset For Road Bike

Top-Fire Lightweight Hub carbon road bike wheels are constructed from Toray T700 & T800. Best bike wheels with 20mm width and 20mm depth weigh only 920±15g.

  • Item NO.:

    WH-RT20-V
  • Payment:

    Paypal, Bank Transfer, West Union
  • Product Origin:

    Xiamen,China
  • Color:

    UD/3K/12K(Customized Painting Acceptable)
  • Shipping Port:

    XIAMEN
  • Product Detail

Top-Fire 700C 20mm Width 20mm Depth Lightweight Hub Tubular Rim Brake Carbon Wheelset For Road Bike


Product Featur

  • A strong and seriously wide yet lightweight carbon rim, with an aero-rounded profile for excellent handling and speed.
  • Toray T700/T800 unidirectional and 3K weave carbon-fibre with 3K weave bed and spoke areas.
  • High TG resin provides extremely reliable braking and durability for longer descents. We lab test all our rims to very high braking temp (200 C) to push their limits.
  • 4D Drill Technology. The 4 directions angled spoke drilling holes that follow the path of the spokes. Make the rim greater strength and durability.
  • Both Shimano 11/12s and Sram 12s XDR freehub optional.
  • High end Sapim CX-Ray spokes, aero and light.

*All of our carbon road rims fit this lightweight hub.


Specification

Item NO.:

WH-RT20-V
Braking System:e
Rim Brak
Applicable Bicycle:
Road Bicycles
Appearance:
Matte/Glossy/Textreme
Material:
Full carbon fiber (Toray T700&T800)
Spoke Hole:
18/21H
Rim width:
20mm
Rim Depth:
20mm
Type:
Tubular
Hub:
Lightweight Hub

Shimano and Sram 11-12s freehub optional

Spokes:
Sapim Cx-ray
Front Wheel Weight:
400±10g
Rear Wheel Weight:
520±10g
Warranty:
18 months
Max Spoke Tension:
>450kgf


About WH-RT20-V

carbon road bike wheels


About Lightweight Hub

lightweight hubs



Read More For Production Of Carbon Rims By Top-Fire Factory

Read More For Testing Of Carbon Rims By Top-Fire Factory
